Frame
ASSEMBLED DIMENSIONS
148 x 73 x 166 cm / 58” x 29” x 65” (Active footprint: 175 x 73 x 172 cm / 68.9” x 29” x 68”)
ASSEMBLED WEIGHT
126 kg / 278 lbs.
EXTRAS
Water bottle holder, accessory tray
FLYWHEEL WEIGHT
10.5 kg / 23.1 lbs.
FRAME TYPE
Suspension Elliptical Trainer
HANDLEBAR DESIGN
Dual action, stationary with resistance toggles and heart rate grips
MAX USER WEIGHT
147 kg / 325 lbs.
PEDAL SPACING
6.35 cm / 2.5”
PEDAL TYPE
Oversized
POWER INCLINE
N/A
POWER REQUIREMENTS
120 V AC power, 15 A circuit (voltage may vary outside the USA)
RESISTANCE RANGE
20 levels, electronically adjustable
RESISTANCE SYSTEM
ECB magnetic braking system
STEP-ON HEIGHT
23 cm / 9.1”
STRIDE LENGTH
51 cm / 20”
